  3. BRM SLIM 900 – 100W
FabLab Factory pricelist

BRM SLIM 900 – 100W

https://www.fablabfactory.com/web/image/product.template/1038/image_1920?unique=61fc456

11.609,95 € 11609.95 EUR 11.609,95 € Inclusief btw 11.972,95 €

Not Available For Sale

Deze combinatie bestaat niet.

Neem contant met ons op

 Algemene voorwaarden

Delen

Features

Every Slim is delivered with our BRM quality checklist and includes all the components needed to get started with the machine:
A water chiller, air pump, red pointer, non-filtering fume extractor, honeycomb table, LightBurn software, maintenance set, our manual and one lens.

Technical specifications


Working area WxDxH

Maximum table load

Dimensions WxDxH

Max processing speed

Max acceleration

Motor type

Positioning system

Optics cooling

Other standard accessories

Weight

Electrical load

Connectivity

Climate

Laserclass

Laserpointer

 Accuracy

Laser power

Max cutting capabilities (at optimum power)

Attached optics



900x600x180 mm

80 kg

1,600x1,200x1320 mm

800mm/s x-axis, 2000mm/s, 40 mm/s max recommended cutting speed

15,000 mm/s² x-axis, 600 mm/s² y-axis

Stepper motor

Belt drive

Passively cooled

135 W air pump | Maintenance kit | Manual

250 kg

2 x 230 VAC,  50 Hz, max 2.3 kW

USB-cable and network

17-23°C, 50-60%

Laser class 1

650 nm, <5 mW

0.1 mm cutting, 420 dpi engraving*

100-130 W

12-85% | 15 mm acrylaat

50.8 mm

Premium roller rotation ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​€995​

Premium claw rotation ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​€995​

Filter unit  ​ ​ ​ ​ ​ ​​BRM Extractor XL Replacement filters: - Pre filter - Combined filter ​ ​ ​ ​ ​ ​ ​ ​ ​ ​€5,495

Lens shaft set ​ ​ ​ ​ ​ ​​Choice of: - 38.1 mm - 63.5 mm - 101.6 mm  ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​€195

Acrylic cutting grid ​ ​ ​ ​​​These grids (400 x 600 mm) ensure reflection-free cutting ​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​€29.50

Turn-off delay ​ ​ ​​ ​ ​ ​​Timed exhaust shutdown controlled by the machine  ​ ​ ​ ​​ ​ ​ ​ ​ ​ ​ ​ ​€​295​

Work table ​ ​ ​ ​ ​ ​​Slat table ​ ​ ​ ​ ​ ​ ​ ​ ​​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​​€334.50

Autofocus ​ ​ ​ ​​ ​ ​ ​​Ultrasonic auto focus ​ ​ ​ ​ ​ ​ ​​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​​€395

Air supply ​ ​ ​ ​ ​ ​ ​​Software-controlled air valve ​ ​ ​ ​ ​ ​​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​​€395
